ICT Protege WX Single Door DIN Rail Controller
- Brand
- ICT
- Model
- PRT-WX-DIN-1D
- Part number
- PRT-WX-DIN-1D
- Availability
- Ordered on demand
- Datasheet
- Manufacturer specifications ↗
A single controlled door, such as a server room, main entrance or small office
Request a quoteSpecifications
| Platform | Protege WX, web-managed |
|---|---|
| Doors | 1 (2 RS-485 readers, entry and exit) |
| Inputs | 2 multi-purpose |
| Outputs | 1 Form C relay |
| Network | Onboard 10/100 Ethernet |
| Module network | Encrypted RS-485, up to 250 modules over 900m |
| Encryption | AES 128, 192 and 256 bit, factory-loaded HTTPS certificate |
| Processor | 32-bit RISC with 2GB memory |
| Mounting | DIN rail, indoors within the protected area |
What this is for
The one-door version of the Protege WX controller, for a site that needs a single controlled door today with room to grow. It is managed from its built-in web interface, and the door rules are held in the controller itself.
It handles one door with an entry and an exit reader over RS-485. More doors can be added later with reader expanders on the same module network, without replacing the controller.
A working door also needs a 12V supply, an enclosure, the readers, the lock and its power, a door contact and an exit button.
What you also need
This item is part of a system. A working installation needs each of these.
- ✓ A 12V DC supply with battery backup
- ✓ A lockable DIN rail enclosure
- ✓ RS-485 readers, such as ICT tSec readers
- ✓ The lock, door contact and exit button for the door
