Ready System
Warehouse after hours: alarm on roller shutters, doors and the stock floor
- Brand
- Urban Eye Security
- Part number
- PKG-AJAX-WHSE
System at a glance
| Control panel | Ajax Hub 2 Plus, 10 of 200 device slots used |
|---|---|
| Doors | 3 DoorProtect Plus, two for roller shutters and one for the staff door |
| Floor | 2 dual-tech MotionProtect Plus, 1 GlassProtect |
| Arming | Keypad Plus with codes and cards |
| Alarm | outdoor StreetSiren, up to 113dB |
| You still need | a roller shutter contact for each shutter, a SIM card and data plan |
What the kit includes
- ✓ 1x Ajax Hub 2 Plus control panel
- ✓ 1x Ajax ReX 2 range extender
- ✓ 3x Ajax DoorProtect Plus opening, shock and tilt detectors
- ✓ 2x Ajax MotionProtect Plus dual-tech detectors
- ✓ 1x Ajax GlassProtect glass-break detector
- ✓ 1x Ajax Keypad Plus
- ✓ 1x Ajax StreetSiren
- ✓ SmartBracket mounts and pre-installed batteries
Not included
Listed here so it does not appear as an extra cost later.
- ✕ Installation and commissioning
- ✕ Roller shutter contacts, quoted per door
- ✕ Wireless signal survey
- ✕ SIM card and data plan for the hub
- ✕ Fire detection (FireProtect 2 sold separately)
- ✕ Monitoring, quoted separately: Urban Eye PRO Monitoring or your own security firm
- ✕ Elevated-access labour
Choose this when
- ✓ Warehouses and godowns with roller shutter loading doors
- ✓ Sites too large for one hub's radio reach
- ✓ Drafts and heat sources cause false alarms with ordinary PIR detectors
Look elsewhere when
- ✕ The building is a small shop or office: see the shop alarm kit
- ✕ You need the full written scope with access control and a site plan: see the warehouse scope
- ✕ You need detection along an outside fence line
Send this to your client
A summary of the scope without prices or a link back to us, so you can share it and keep your own pricing.
Why this kit is built this way
System objective: an alarm after hours on the roller shutters, the doors and the stock floor of a warehouse or godown too large for one hub's radio reach. Roller shutters are the real doors of a godown, so they are covered first, then movement on the floor.
Why this configuration
- Roller shutters covered. A roller shutter contact wires into a DoorProtect Plus set to its roller shutter input, the connection Ajax documents for shutters, with the wire kept within 3 metres.
- Doors that report forcing. DoorProtect Plus also detects shock and tilt, so an attempt to lever a door raises the alarm before it opens.
- Extended coverage. The ReX 2 range extender carries the link a further 1,700m, taking the hub-to-detector reach to as much as 3,400m in open space.
- Fewer false alarms on the floor. MotionProtect Plus only raises an alarm when its microwave sensor confirms what the PIR sensor detected.
What the kit includes
| 1x | Ajax Hub 2 Plus (up to 200 wireless devices) |
| 1x | Ajax ReX 2 (extends hub reach to 3,400m in open space) |
| 3x | Ajax DoorProtect Plus (two for roller shutters, one for the staff door) |
| 2x | Ajax MotionProtect Plus (dual-tech microwave + PIR) |
| 1x | Ajax GlassProtect (9m acoustic glass-break coverage) |
| 1x | Ajax Keypad Plus (codes and cards for arming) |
| 1x | Ajax StreetSiren (up to 113dB at 1m, IP54 weatherproof) |
Quoted per door
- A roller shutter contact with a normally closed output for each shutter, fixed to the floor or guide
Hardware bundle only. Installation and site survey quoted separately. The full written scope for a warehouse, with the site plan, is the warehouse and godown security scope.
Compatibility
All units in this kit run on Ajax's encrypted Jeweller radio protocol and pair to the included Hub 2 Plus, with the ReX 2 extending radio range further. Any other Jeweller device from our Intrusion & Alarm collection, including fire detectors, can be added to the same hub.
